GITI GAO852 11.00R20 12.00R20

Features

  • Reinforced belt construction
  • Reinforced casing and bead structure
  • Sidewall protection rib
  • Unique groove width design
  • Tie-bar design between center blocks
  • Type-Z shape block pattern design
  • Anti-Cut and Chip compound developed for mixed conditions of working in the mine and delivers materials out of mine services

Specifications

GITI GAO852
Size PR Load Index Speed Rating Standard Rim Maximum Load (mm) Maximum Pressure (kPa) Tread Depth (mm) Outer Diameter (mm) Section Width (mm) TL/TT
kg lbs kPa psi
 11.00R20 18 152/149 F 8.00 3550/3250 7830/7160 930/930 135/135 23.5 1096 293 TT
 12.00R20 20 156/153 F 8.50 4000/3650 8820/8050 900/900 130/130 24.5 1136 315 TT
