L4 10-16.5
Features
L4 10-16.5 Features:
* This pattern is engineered to provide superior flotation characteristics resulting in a turf friendly tire that will not damage grass or roots
* Full, flat profile provides increased stability
![](https://www.tnr-international.com/wp-content/uploads/2022/03/3-4.png)
![](https://www.tnr-international.com/wp-content/uploads/2022/03/3-3.png)
![](https://www.tnr-international.com/wp-content/uploads/2022/03/3-2.png)
Tyre Size | Ply Rating | Tyre Type | Tread Depth | Section Width | Overall Diameter | Max. Speed | Infl. Pressure | Max. Load | Standard Rim | ||||||
(mm) | (32nds) | mm | inch | mm | inch | km/h | mph | kPa | psi | kg | lbs | ||||
10-16.5 | 8 | TL | 27.0 | 34.0 | 264 | 10.4 | 773 | 30.4 | 10 | 5 | 410 | 60 | 1880 | 4140 | 8.25 |
10-16.6 | 10 | TL | 27.0 | 34.0 | 264 | 10.4 | 773 | 30.4 | 10 | 5 | 520 | 75 | 2135 | 4710 | 8.25 |
12-16.5 | 10 | TL | 33.5 | 42.2 | 307 | 12.1 | 831 | 32.7 | 10 | 5 | 450 | 65 | 2540 | 5600 | 9.75 |
12-16.6 | 12 | TL | 33.5 | 42.2 | 307 | 12.1 | 831 | 32.7 | 10 | 5 | 550 | 80 | 2865 | 6320 | 9.75 |
10.5/80-18 | 12 | TL | 16.0 | 20.2 | 274 | 10.8 | 882 | 34.7 | 30 | 20 | 430 | 62 | 1465 | 3230 | W9 |
12.5/80-18 | 12 | TL | 30.0 | 38.0 | 308 | 12.1 | 985 | 38.7 | 30 | 20 | 370 | 53 | 2650 | 5845 | W9 |
16.9-24 | 14 | TL | 26.0 | 32.8 | 429 | 16.9 | 1309 | 51.5 | 30 | 20 | 280 | 40 | 2720 | 6000 | W15L |
16.9-28 | 14 | TL | 28.0 | 35.3 | 429 | 16.9 | 1410 | 55.5 | 30 | 20 | 280 | 40 | 2900 | 6395 | 15.00 |
16.9-30 | 14 | TT | 39.0 | 49.1 | 430 | 16.9 | 1485 | 58.5 | 30 | 20 | 270 | 39 | 2950 | 6500 | W15L |
19.5L-24 | 12 | TL | 25.0 | 31.3 | 495 | 19.5 | 1314 | 51.7 | 40 | 25 | 230 | 33 | 3450 | 7605 | DW16A |
21L-24 | 14 | TL | 53.0 | 66.0 | 533 | 21.0 | 1375 | 54.2 | 40 | 25 | 250 | 36 | 4200 | 9240 | DW18L |
L4 10-16.5
